| Std work rest(dia) | ¢1 〜50mm |
| Special work rest(dia) | ¢40~ 120mm |
| Grinding wheel size(dia x width x hole) | φ510×205×φ228.61 |
| Regulating wheel size (dia x width x hole) | φ305×205×φ111.2 |
| Grinding wheel and guide wheel spindle form: | Hydrostatic |
| Spindle rotation accuracy | <0.0015mm |
| Guide wheel transmission mode | Worm gear reducer drive |
| Oil supply pressure | 20-25kg/cm |
| Wheel speed | 100～1550 R.P.M Frequency conversion control |
| Adjust wheel speed | 1～300R.P.M |
| Wheel drive motor | 20HP(15kw)AC380V/50HZ |
| Adjust wheel drive motor | 4HP（3.0kW）AC200V/50HZ |
| Hydraulic pump drive motor | 2HP(1.5kw )AC380V/50HZ |
| cooling pump drive motor | 1/4 HP(180w)AC380V/50HZ |
| Adjusting wheel feed hand wheel | 3.5mm/per revolution 0.05mm/per scale |
| Adjustment Wheel Fine Adjustment Hand Wheel | 0.7mm/per revolution 0.001mm/per scale |
| Table feeding servo motor | Delta 3.0KW |
| Table feed screw | Japan Ø50 THK |
| Table feeding accuracy | 0.001 mm |
| Trim feed handwheel | 2mm/per revolution 0.01mm/per scale |
| Adjust wheel tilt angle | +6°～-5 |
| Adjust wheel turning angle | ±6° |
| operating system | Delta PLC |
| Operation interface | touch screen |
| Mechanical size (L×W×H) | 2550×1960×1550mm |
| Packing size (L×W×H) | 2400×2000×1800mm |
| Mechanical weight | 3800Kg |
| Packing weight | 4000Kg |
